Atlas 215-24

  • Add to Cart

    Obtain a formal quote for this configuration by clicking the “REQUEST A QUOTE” button. Then, enter your email address and provide any pertinent configuration notes. You will then receive an email with a link to a pdf of the quote. The Pogo Linux sales engineering team will review your configuration and respond via email with any comments or suggestions.

  • View Specs

    Obtain a formal quote for this configuration by clicking the “REQUEST A QUOTE” button. Then, enter your email address and provide any pertinent configuration notes. You will then receive an email with a link to a pdf of the quote. The Pogo Linux sales engineering team will review your configuration and respond via email with any comments or suggestions.

Generate PDF review my config

$7,222.88

  • AMD EPYC 9004 Series Processor
  • Up to 3072GB of DDR5 ECC Reg Memory
  • 24x 2.5" Hot-swap NVMe SSD Bays
  • 2x 10GBe Onboard
  • 3x Expansion Slots
  • 1000W Platinum Redundant Power Supplies
Atlas 215-24
Processor and Memory
CPU
Memory
OS Drives
OS Drives
Hard Disk Drives
NVMe U.2 Selection
Optional OCP Networking
PCI Express Expansion Cards
PCIe Slot 1
PCIe Slot 2
PCIe Slot 3
PCIe Slot 4
Operating Systems
Operating System
RAID Configuration
RAID Level
Support Options
Warranty and Support

Atlas 215-24

Atlas 215-24
Processor Support
CPU
AMD EPYC 9004 Series Processor
Socket
AMD Socket SP5
Memory
Dimm Slots
(24) DIMM slots
Type
RDDR5 4800 w/ ECC
Capacity
Up to 3,072GB RDIMM
OnBoard Devices
IPMI
Aspeed AST2600
Network Controller
Intel X710-AT2
Input/Output
LAN
(2) 10GbE ports
IPMI
(1) GbE dedicated for IPMI
USB
(1) USB3.2 Gen.1 conn. (Type-A) / (1) USB3.2 Gen.1 header / (2) USB3.2 Gen.1 ports (@ front) / (2) USB3.2 Gen.1 ports (@ rear)
VGA
(1) D-Sub 15-pin port
Serial Port
(1) DB-9 COM port
Chassis
Form Factor
2U
Depth
26.77"
Height
1.69"
Width
17.26"
Average Weight
100Lbs
Expansion
PCI-E 1
1) M7136T70-R24-2F riser card for for (2) FH/HL PCIe 5.0 x16 slots
PCI-E 2
(1) M7136T70-L28-1F riser card for for (1) FH/HL PCIe 5.0 x8 slot
Drive Bays
Hot Swap
26x NVMe U.2
OS
2x M.2 NMVe
System Cooling
Fan 1
(3) hot-swap 8056 fans
Power
Spec
1,000 Watts (100-127V AC input) / 1,600 Watts (200-240V AC input) 80 plus Platinum Redundancy1+1
Input
AC 100-127V/13A / AC 200-240V/9.5A
